Creating a good compiler is a two-fold juggling task. On one hand, the compiler itself should run quickly and use very little memory. On the other hand, the machine code it produces should actually be fast too. Over the last few months, I have discovered that balancing between these two values is an art form. Very rarely do we get to cheat and get both at the same time. When it comes to my latest project Wago, my friend Jairus and I stumbled onto a paper that changed our direction completely. This paper is called "Valent-Blocks: Scalable High-Performance Compilation of WebAssembly Bytecode For Embedded Systems." This technique was designed to be usable by resource-constrained systems, and naturally, it turned out to be very valuable in many other places as well. The central idea? The compiler does not need to emit machine code as soon as it reads an instruction. Instead, it can accumulate a small very focused representation using a stack machine and make better decisions once "side effects" actually occur or when something actually needs to become a value. An example Consider a function that calculates (a + 3) * b. First, let's look at an equivalent function in JavaScript. function example(a, b) { return (a + 3) * b; } Typically, I like to use the "wat" format, which stands for "WebAssembly Text Format." This syntax is similar to assembly in a lot of ways, but it's easy to follow along. Each instruction operates on a stack machine instead of on registers. (func $example (param $a i32) (param $b i32) (result i32) local.get $a i32.const 3 i32.add (; a + 3 ;) local.get $b i32.mul (; $val * b ;) ) A direct translation of this into machine code might naively turn this into a very big un-optimized mess. ; local.get $a mov eax, DWORD PTR [rbp - 4] push rax ; i32.const 3 mov eax, 3 push rax ; i32.add pop rcx pop rax add eax, ecx push rax ; local.get $b mov eax, DWORD PTR [rbp - 8] push rax ; i32.mul pop rcx pop rax imul eax, ecx push rax ; result pop rax ret Each instruction immediately commits to a physical representation for its result. In doing so, the compiler throws away useful information after almost every instruction. Additionally, the compiler threw away useful information after each and every instruction. It results in: 5 pushes 5 pops 2 local loads 1 constant materialization 1 add 1 multiply Instead, what if we stopped mirroring the WebAssembly operand stack into actual machine-stack operations? We can keep a "symbolic" stack during compilation and delay the machine-code decisions until we have more information. Step 1: local.get $a Our algorithm can simply push a "LocalGet($a)" to a stack. stack.push(LocalGet($a)) We skip the part where we emit machine instructions. Step 2: i32.const 3 stack.push(I32Const(3)) Now we have two values on top of the stack. ┌──────────────┐ │ I32Const(3) │ ├──────────────┤ │ LocalGet($a) │ └──────────────┘ Again, we skip the machine code. No side effects have happened yet anyway. Step 3: i32.add Now we need to add the two items on the stack. Instead of emitting an actual add instruction, we can simply produce an I32Add(LocalGet($a), I32Const(3)) and push it to the stack. Pop each of the items off the top of the stack one by one, and then push the result back on. Notice that the right operand is popped first because it was pushed last. We then reconstruct the operands in their original order. right = stack.pop() left = stack.pop() stack.push(I32Add(left, right)) Step 4: The rest of the function The last two instructions follow the same pattern: stack.push(LocalGet($b)) // local.get $b right = stack.pop() left = stack.pop() stack.push(I32Mul(left, right)) And we are done! ... Just kidding. We are done building the expression, but we still have not generated any machine code. Eventually, something has to consume the value. In this case, we have reached the end of the function, and the function must return the value on top of the Wasm stack. This forces us to resolve, or condense, our deferred expression into actual machine instructions. This is where things get a bit more complicated. Step 5: Resolve a + 3 We need to move "a" into a register and add 3 to it, leaving the resulting value inside the register. mov eax, DWORD PTR [rbp - 4] add eax, 3 We must assume that the parameter of the function exists at [rbp - 4], but it only results in a single load operation. We use eax here to keep a running value of the item on top of the stack, as you will see. Step 6: Resolve the multiplication Finally, we perform the multiplication in a single step here using a memory operand which points to b, and follow it up with a ret which signifies the end of the function. The return value is already conveniently stored exactly where it needs to be. imul eax, DWORD PTR [rbp - 8] ret Let's put it all together now! mov eax, DWORD PTR [rbp - 4] add eax, 3 imul eax, DWORD PTR [rbp - 8] ret Wow. That's a big difference. The important part is not only that this code is shorter. By waiting, the compiler kept useful information alive. Since 3 remained a constant, it became an immediate operand to add. Since $b remained a local reference, the multiplication could consume it directly from memory. The result of a + 3 never needed a stack slot at all; it stayed in eax until the multiplication consumed it. In this simplified example, leaving the return value in eax, exactly where it needs to go, is another nice benefit. This is the main technique used by my latest project called Wago, which is a single-forward-pass WebAssembly-to-native JIT compiler written in Go. You can check it out here: wago-org / wago a wonderfully quick, compact, and extensible webassembly runtime for go ╦ ╦ ╔═╗ ╔═╗ ╔═╗ ║║║ ╠═╣ ║ ╦ ║ ║ ╚╩╝ ╩ ╩ ╚═╝ ╚═╝ a wonderfully quick, compact, and extensible webassembly runtime for go documentation · getting started · plugins · benchmarks · discord · sponsor us Wago is a pure-Go WebAssembly engine that compiles Wasm directly to native machine code. Note Wago is still beta. APIs and .wago artifacts may change. Why Wago? Fast and lightweight. Using a few kilobytes of ram, we compile 5x faster and execute 40% quicker than wazero. Pure Go. Embed Wago without CGO while keeping straightforward Go builds and cross-compilation. Standards Compliant We pass the official WebAssembly test suite, millions of fuzzes, and many real-world corpora. Extensible by design. WASI, the Component Model, and other host capabilities live outside the core runtime as plugins. Standalone executables Compile your .wasm to tiny native executables. Great for CLIs. Install On macOS and Linux: … View on GitHub Wago compiles Wasm directly to machine code without using a whole-function intermediate representation, while using very little memory at compile time. You can check out some of our computed benchmark numbers and install it here at the wago homepage. As a bit of a warning, this software is currently in beta, which means that we are trying to improve stability on both amd64 and arm64 across Linux, macOS, and Windows. If you happen to need a web assembly runtime, we would appreciate it if you took the time to try it out. Thanks for reading and happy coding. Joshua Tenner
